Name: Chemicals Horizontal Grinding Mill Disc Sand Mill For Paint
Brand: Chongqing Degold Machine Co., Ltd.
Price: 251.00 USD
Availability: InStock

Home > products > Bead Mill >

Chemicals Horizontal Grinding Mill Disc Sand Mill For Paint

chemicals horizontal grinding mill

horizontal grinding mill disc

disc sand mill for paint

Certification:

Request A Quote

Chemicals Horizontal Grinding Mill Disc Sand Mill For Paint

Product Details

Model NO.:

ZM5

Object:

Milling Cutter

Warranty:

12 Months

Transport Package:

Fumigation Wooden Box

Specification:

CE, ISO9001: 2000, SGS

Trademark:

DEGOLD

Origin:

Chongqing, China.

HS Code:

8479820090

Supply Ability:

100sets/Year

Mill Type:

Disc Grinder

Suitable Grinding Medium:

Zirconium/Zirconia/Zircon Beads

Function:

Wet Grinding For Particle Size Reduce

Applicable Industry:

Paint, Ink, Pigment Etc.

Application:

Chemical

After-Sales Service Provided:

Engineers Available To Service Machinery Overseas

Customization:

Available | Customized Request

Highlight:

chemicals horizontal grinding mill

horizontal grinding mill disc

disc sand mill for paint

Payment & Shipping Terms

30L Nano Horizontal Bead Mill Impeller ZM30D/ZM30S/ZM30DB/ZM30SB Cooling Water Jacket

Get Best Price

Video

5L Horizontal Sand Mill for Paints and Inks ZM5 Series Wet Grinding Capability

Get Best Price

Video

Customized Request ZM20S1210 Horizontal Sand Mill for Paint Customization Pesticide

Get Best Price

Video

ZM15 Horizontal Bead Mill Machine with Inverter Speed Adjustment at Affordable

Get Best Price

+86 18716271716

jiang@chinadegold.com

86-187-1627-1716

Contact Now

Product Description

Long Service Life Disc Grinder Paint Horizontal Sand Mill Machine with ISO9001 2000

Specifications

ZM5DB4410-X Above picture is for reference only	Chongqing Degold Machine Co., Ltd. DEGOLD 5L diaphragm pump Ex proof agitator sub-micron tungsten carbide grinding cylinder&disk horizontal sand mill for paint DEGOLD large scale production sand mill is designed for production. ZM-X series sand mills are disk type sand mill machines. The grinding shaft drives all grinding medium inside the grinding chamber of the sand mill. Dynamic gap separator makes sure products and grinding medium separated well. Special inner grinding chamber and larger output area designs to make sure better particle size reduction. Mold steel, tungsten carbide, polyurethane and ceramic are four kind materials option in ZM-X series sand mill. Except the materials selection, the inverter, explosion proof etc. are also optional in this series sand mill. Please contact with us to get more exactly information.
Series	ZM5-X
Volume	5L
Seal Type	single mechanical seal
Ex proof Type	Ex proof
Inner grinding cylinder material	tungsten carbide
Grinding disc material	tungsten carbide
Pump type	diaphragm pump
Mill speed adjustment way	without inverter
Please refer to fllowing table "ZM-X Series Introduction" for more technical information or contact with us. Technical data are different if there are some customized constructions.

Applications

Paint	Automotive Paint Top Coat Clear Coat Cathodic Dip Coating Coil Coating Fillers Construction Paint Wood Paint Marine Paint Dispersion Paint Road Marking Paint	Printing Inks	Screen Printing Inks Flexo Printing Inks Rotogravure Inks Sheet-fed Ink jet Heat-set Cold-set
Agrochemistry	Fertilizer Pesticides Suspension Concentrate(SC)	Pigments / Dyes	Pigment Production Titanium Dioxide
Ceramics / Glass	Ceramic Pigments Table Ware / Sanitary Ware Technical Ceramics	Ores / Minerals / Metals	Graphite Talc Calcium Carbonate
Life Science	Biotechnology Cosmetics / Personal Hygiene Pharmaceuticals	Food	Cocoa Liquor
More applications, please contact with us

ZM-X series Introduction

Following is the technical table of ZM-X series sand mills produced by Chongqing Degold Machine Co., Ltd.

ZM-X Series	ZM5-X	ZM15-X	ZM20-X	ZM30-X	ZM50-X	ZM100-X	ZM200-X
Effective grinding chamber volume (L)	5	15	20	30	50	100	200
Main motor power (kW)	11	18.5	22	30	37-45	45-55	55-75
Grinding shaft rotary speed (r/min)	1650	1200	1200	1120	900	700	550
Adjustable range of materials flow (L/min)	0~2	0~2	0~10	0~10	0~60	0~60	0~150
Max. cooling water consumption (t/h)	1	1	2	2	2.5	2.5	3~4
Estimated productivity (kg/h)	15~150	40~400	50~500	60~800	150~1500	150~1500	200~2000
Length	1250	1560	1670	1760	1970	2175	2150
Width	900	1050	1050	1050	1150	1200	1200
Height	1250	1550	1565	1585	1650	1880	2150
Net weight (kg)	700	800	1000	1150	1350	2000	2500
Ex proof Type	Ex proof / Non Ex proof
Seal Type	Single Mechanical Seal / Double Mechanical Seal
Inner Grinding Cylinder Material	SS304 / Hard Steel / Mold Steel / Tungsten Carbide / Ceramic / PU
Grinding Disc Material	SS304 / Hard Steel / Mold Steel / Tungsten Carbide / Ceramic / PU
Pump Type	Diaphragm pump / Gear Pump / Screw pump
Mill Speed Adjustment Way	With inverter / Without inverter
Note: Technical data are different if there are some customized constructions. We'd like to send you the suitable model sand mills for your production, please feel free to contact with us.

Series Of Horizontal Sand Mill

Following is the introduction of horizontal sand mills produced by Chongqing Degold Machine Co., Ltd.

Series	Description	Browse
ZM LAB	laboratory sand mills are used for research and development. volume: 0.3L \| 1.4L	Browse Products
ZM	ZM series sand mills are suitable for middle viscosity water based and solvent based poducts wet grinding and dispersion. volume: 5L \| 15L \| 20L \| 30L \| 50L	Browse Products
ZM-X	ZM-X series sand mills are suitable for nano meterswet grinding and dispersion. volume: 5L \| 15L \| 20L \| 30L \| 50L \| 100L \| 200L	Browse Products
ZM-E	ZM-E series sand mills are rotor gap separator sand mills for nano wet grinding. volume: 20L \| 50L \| 100L \| 200L \| 300L \| 500L \| 1000L	Browse Products
ZM-K	ZM-K series are conical pin typesand mills. This series sand mills are suitable for high viscosity materials wet grinding and dispersion. volume: 6L \| 10L \| 25L \| 60L \| 150L	Browse Products
ZM-T	ZMT series are turbo designsand mills which are suitable for nano meters wet grinding and large productivity. volume: 8L \| 18L \| 25L \| 60L	Browse Products
Any question, please contact with us.

Company Introduction

Chongqing Degold Machine Co., Ltd.

Degold is chemical equipment & machinery (wet grinding bead/sand/pearl mill machine) manufacturer in China

Degold designs, develops, constructs, and installs production lines and advises, trains customers.

Chongqing Degold Machine Co., Ltd. has always endeavored to develop grinding and mixing technique in chemical industry.
Now we have developed various models Horizontal Sand Mills and Dispersers to fulfill industrial production needs ranging from paints, inks, pharmaceuticals, food, dyes, cosmetics, petrochemicals, and non-mental mines.

Certification

All Degold technical experts have been in this field since 80s in the 20th century. We produce strictly as the requirements of ISO9001:2008 Quality System and CE standards.

Customers

Machines are popular in domestic and oversea market. We have cooperated with so many famous painting and powder coating manufactures such as Akzo Nobel, 3M, Clariant, and Sherwin-Williams Co., Ltd. etc.

Markets

From 2007, we have begun to service oversea customers directly. Our machines have been exported to many countries and regions such as Australia, Argentina, Belgium, Brazil, Colombia, Chile, Indonesia, India, Iran, Malaysia , New Zealand, Peru, Paraguay, Pakistan, Poland, Singapore, South Africa, Spain, Tunisia, Thailand, Uruguay , Vietnam etc
